Processor
Intel Kaby Lake Celeron 3965U, 2.20 GHz, 2M Cache;
Intel Skylake Core i3-6100U, 2.30 GHz, 3M Cache;
Intel Kaby Lake Core i3-7100U, 2.40 GHz, 3M Cache;
Intel Kaby Lake Core i5-7200U, up to 3.10 GHz, 3M Cache
System Memory : DDR4 SO-DIMM slot x 2, max. 16GB
Storage Device : SATA x 2
RAID Function : N/A
Intel vPro Support : N/A
TPM Support : N/A
Power Supply : 12V/60W
OS Support : Windows 7/POSReady 7/Windows Embedded 8.1 Industry 64 bit/Windows 10 IoT 64 bit/Linux per request for Skylake processor
Windows 10 IoT 64 bit for Kaby Lake processor
Spill & resistance : N/A
Display & Touch
LCD : 15" TFT LCD
Resolution : 1024 x 768
Touch : True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O Expansion
Serial Port :3, DB9 x 1 + RJ50 x 2, 5V/12V support on all COM ports
Standard USB Port : 5, USB 3.0 x 2 + USB 2.0 x 3
Parallel Port : N/A
PoweredUSB Port : Optional PoweredUSB module with 24V + 12V (USB 3.0 x 1 will no longer be available with the PoweredUSB module)
LAN Port : 10/100/1000 Mb x 1
Display Port : VGA via proprietary connector (12V support for Posiflex monitors) x 1+ mini DP x 1
CR Port : 1, control 2 CR via optional Y-cable, supporting 24V cash drawer
PS/2 Port : N/A
UPS Port : N/A
Audio : Internal 2W speaker x 1
Expansion Slot : M.2 slot x 1
Physical Dimension
Dimension (W x D x H in mm) : 368 x 207 x 325
Weight (N. W. in kg) : 5.4
