system ConfigurationProcessor : Intel Bay Trail J1900 Quad Core CPU, up to 2.42 GHz, 2M Cache
System Memory : DDR3L SO-DIMM x 1, max. 8GB
Storage Device : SATA x 1, SATA SSD default
RAID Function : N/A
Intel vPro Support : N/A
TPM Support : N/A
Power Supply : 12V/40W
OS Support : Windows 7/POSReady 7/Windows Embedded 8.1 Industry/Windows 10 IoT/Linux per request
Spill & resistance : N/A
Display & Touch
LCD : 15" TFT LCD
Resolution : 1024 x 768
Touch : True-flat PCAP touch with multi-touch support (IP65 on front panel)
LCD : 15" TFT LCD
Resolution : 1024 x 768
Touch : True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O Expansion
Serial Port : 4, DB9 x 3 + RJ50 x 1, 5V/12V support on all COM ports
Standard USB Port : USB 2.0 x 5
Parallel Port : 1, via optional conversion cable through service window
PoweredUSB Port : N/A
LAN Port : 10/100/1000 Mb x 1
Display Port : VGA x 1, 12V support for Posiflex monitors
CR Port : 1, control 2 CR via optional Y-cable
PS/2 Port : 1, via optional conversion cable through service window
UPS Port : N/A
Audio : Buzzer only
Expansion Slot : N/A
Serial Port : 4, DB9 x 3 + RJ50 x 1, 5V/12V support on all COM ports
Standard USB Port : USB 2.0 x 5
Parallel Port : 1, via optional conversion cable through service window
PoweredUSB Port : N/A
LAN Port : 10/100/1000 Mb x 1
Display Port : VGA x 1, 12V support for Posiflex monitors
CR Port : 1, control 2 CR via optional Y-cable
PS/2 Port : 1, via optional conversion cable through service window
UPS Port : N/A
Audio : Buzzer only
Expansion Slot : N/A
Physical Dimension
Dimension (W x D x H in mm) : 372 x 320 x 252.7
Weight (N. W. in kg) : 5.86
Dimension (W x D x H in mm) : 372 x 320 x 252.7
Weight (N. W. in kg) : 5.86
